JA Solar JAM54D40/LR 470W Double Glass Black solar module

Product description

JA Solar JAM54D40/LR 470W Double Glass Black

The JA Solar JAM54D40/LR 470W Double Glass Black is a high-performance photovoltaic module that combines advanced N-type solar cell technology with a durable double-glass construction. With a rated output of 470 Wp and module efficiency of up to 23.5%, this solar panel is an excellent option for installations seeking efficient solar energy production. Its black frame provides a sleek, modern appearance that complements contemporary residential and commercial buildings. The glass-glass construction contributes to mechanical strength and durability, while the advanced cell technology helps reduce initial degradation and supports stable long-term performance. The JA Solar JAM54D40/LR 470W solar panel is suitable for a wide range of photovoltaic installations, offering an attractive combination of power, efficiency and modern design.

470 Wp rated power for efficient solar electricity generation.
Up to 23.5% module efficiency for high energy production per square metre.
N-type solar cell technology designed to support stable performance and low initial degradation.
Double-glass construction for a robust and durable module structure.
Stylish black frame suited to modern rooftop installations.
108 solar cells for efficient conversion of sunlight into electricity.
Suitable for residential and commercial PV systems.

JA Solar JAM54D40/LR 470W Double Glass Black solar module

Product specifications

Number of pieces in 1 package

l x w x h (mm)

1762 x 1134 x 30

Cell Type

Monocrystalline

Frame

Black anodized

Colour

Black

Module efficiency (%)

23.5

Type of glass

Tempered Glass / Glass

Brand

JA Solar

Power (Wp)

470

Factory Warranty (Year)

Power Warranty (Year)

Reference

JAM54D40/LR470W
